MOTION TREK ANCHOR/BEARING ASSEMBLY

The Spectrum Aquatics Motion Trek Anchor/Bearing Assembly is a dedicated mechanical replacement and structural rebuild component engineered for the mast rotation base of the Motion Trek BP 350 and BP 400 series pool lifts.

Functional Overview

This assembly houses the primary mechanical rotational bearing and anchor interface sleeve that allows the pool lift mast to rotate smoothly under full commercial payload ratings:

• Rotational Support: Houses high-strength, low-friction composite or stainless thrust bearing components designed to absorb dynamic cantilever torque, axial loads, and lateral side-load stresses while enabling continuous 360-degree powered rotation.

• Mast & Socket Interface: Acts as the precision-machined mechanical connection between the rotating vertical mast column and the stationary 2.375-inch in-ground deck anchor socket, eliminating excess play, wobble, or binding during user transfers.

• Corrosion Resistance: Constructed from passivated marine-grade stainless steel and chemical-resistant polymer bearing surfaces engineered to resist seizing, pitting, and degradation from constant exposure to chlorinated water, bromamines, and saltwater atmospheres.

• Maintenance & Rebuild: Typically utilized to refurbish lifts experiencing rotation stiffness, audible grinding, or mechanical play caused by long-term high-volume facility usage or dry-bearing wear.
